规格 长×宽×厚mm | 000级精度 μm | 00级精度 μm | 0级精度 μm | 1级精度 μm |
300x300x50 | 1.5 | 3 | 6 | 12 |
400x300x70 | 1.5 | 3 | 6 | 12 |
400x400x70 | 2 | 3.5 | 6.5 | 13 |
500x500x100 | 2 | 3.5 | 6.5 | 14 |
400x600x100 | 2 | 4 | 8 | 16 |
500x600x100 | 2 | 4 | 8 | 16 |
500x800x130 | 2 | 4.5 | 9 | 18 |
600x900x130 | 2.5 | 5 | 9 | 18 |
600x600x110 | 2.5 | 5 | 10 | 20 |
1000x750x150 | 2.5 | 5 | 10 | 20 |
1000x1000x150 | 2.5 | 5 | 10 | 20 |
900x1200x150 | 2.5 | 5 | 10 | 20 |
1000x1200x150 | 2.9 | 6 | 12 | 24 |
800x1200x150 | 2.5 | 5 | 10 | 20 |
1500x1000x200 | 3 | 6 | 12 | 24 |
1600x1000x200 | 3 | 6 | 12 | 24 |
1000x2000x200 | 3.5 | 7 | 14 | 28 |
1000x2000x250 | 3.5 | 7 | 14 | 28 |
1500x2000x250 | 3.5 | 7 | 14 | 28 |
1000x630x150 | 2 | 7 | 14 | 28 |
1500x2000x300 | 3.5 | 7 | 14 | 28 |
1500x1500x200 | 3 | 6 | 12 | 24 |
1500x3000x300 | 3.5 | 7 | 14 | 28 |
2000x3000x300 | 4.5 | 9 | 18 | 36 |
1600x3000x300 | 3 | 6 | 12 | 24 |
2000x4000x400 | 5.5 | 11 | 22 | 44 |
